SPECIFICATIONS
Gain 15 dB bal in / bal out 15 dB unbal in / bal out
9 dB bal in / unbal out 9 dB unbal in / unbal out
Freq. Response -3 dB @ 5 Hz -3 dB at > 100 kHz
Distortion < .1 % THD typically .01% @ 2 volts @ 1KHZ
Maximum Output 15 volts rms. bal out 8 volts rms. unbal out
Output Impedance 0 - 1000 ohms unbalanced
0 - 2000 ohms balanced
Input Impedance 10 kOhm unbalanced 20 kOhm balanced
CMRR typical -80 Db, 20-20 KHz
Crosstalk typical -90 dB, 20-20 KHz
Output Noise Noise floor < -120 dBV, 20-20 KHz
Power Consumption 25 watts
